| SPECIFICATION | |
| Model Number: Dlux | Height: 1.5-6m |
| SYSTEM MODULE | |
| Fixture Material: Die Cast ADC12+Extrusion Aluminum 6063+Q460 | System Color: Black / Sliver / customized finishes available |
| Sail Area / EPA: 0.33-1.32㎡ | IP&IK Protection: IP65, IK08 |
| Operating Temp: -15℃～+50℃ | Warranty: 5-10 Years |
| LED LIGHT | |
| LED Chips: CREE / OSRAM / LUMILEDS / Nichia / SEOUL | Power Consumption: 10W-100W |
| Output: 110-180LM/W | Light Distribution: T2 / T3 / T4 |
| CCT: 2700K-6500K | |
| Runtime: STD-4 Step dimming | |
| BATTERY | |
| Type: LiFePO4 Passive cell balancing technology Individual cell monitoring / Deeper discharge cycles | Capacity: 60Ah 25.6V (x1) LiFePo4 60Ah 25.6V (x3) LiFePo4 |
| Cycles: 3000 | |
| SOLAR MODULE | |
| Watt: Pmax 800W Monocrystalline | Bird Spikes: Stainless Steel (optional) |
Dimensions: 220x220x6000mm(2000x6000mm-optional) | |
| MOUNTING OPTIONS | |
| Direct bury | |
| Base plate mount | |
